Kia Cadenza: Engine Control System / Injector Troubleshooting

Injector Specifications

Specification ItemSpecificationCoil Resistance (Ω)0.98 ~ 1.14 [20°C(68°F)] ...

Injector Schematic Diagrams

Circuit Diagram ...
