Kia Cadenza: Light bulbs / Light bulb position (Side)

Light bulb position (Rear)

(1) Tail lamp (LED type) (2) Stop and tail lamp (LED type) (3) Back-up lamp (Bulb type) (4) Rear turn signal lamp (Bulb type) (5) Rear side marker (LED type) (6) High mounted stop lamp ...

Headlamp (Low/High beam) (LED type) bulb replacement

If the headlamp (LED type) (1) does not operate, have the vehicle checked by an authorized Kia dealer. The LED lamp cannot be replaced as a single component because it is an integrated unit ...
